Ausstattungsliste: Tannoy VXNET 15Q
Ausstattung & technische Daten
| Performance | |
| System Type | Full Range - Vented |
| Frequency Response (-3 dB) (1) | 60 Hz - 25 kHz |
| Frequency Range (-10 dB) (1) | 47 Hz - 30 kHz |
| Rated Maximum SPL (2) | Average: 126 dB |
| Peak: 132 dB | |
| Dispersion (-6 dB) | 75 degrees (Horizontal) x 40 degrees (Vertical) |
| Driver Complement | 1 x 380 mm (15.00") PowerDual |
| Crossover (DSP Generated) | 1.5 kHz and variable high pass filter for use with subwoofers |
| Directivity Factor (Q) | 12.0 averaged 1 kHz to 8 kHz |
| Directivity Index (DI) | 10.8 averaged 1 kHz to 8 kHz |
| Distortion | |
| 10% Full Power (17.9 V) | 2nd Harmonic 250 Hz: 1.05%, 1 kHz: 0.61%, 10 kHz: 7.79% |
| 3rd Harmonic 250 Hz: 0.10%, 1 kHz: 1.02%, 10 kHz: 1.15% | |
| 1% Full Power (5.7 V) | 2nd Harmonic 250 Hz: 0.30%, 1 kHz: 0.58%, 10 kHz: 2.32% |
| 3rd Harmonic 250 Hz: 0.06%, 1 kHz: 0.52%, 10 kHz: 0.13% | |
| Electronics | |
| Efficiency | >85% typically |
| Damping Factor | 120 ref 8 Ohms |
| Distortion | <0.05% @ 1 kHz - 3 dB output (22 kHz bandwidth) |
| Input Impedance | 5.6 kOhms (unbalanced) |
| 11.2 kOhms (balanced) | |
| Input Sensitivity | 1.4 V (+5.5 dBu) |
| System Type | Dual channel Class D (Bridged) |
| PSU Specifications | |
| Input Connector | Locking Neutrik Powercon |
| Voltage Selection | Automatic (115 / 230 V, 45 - 65 Hz) |
| System Type | High current, high frequency switch mode |
| Efficiency | >90% typical |
| Input voltage | 100 V / 115 V / 230 V nominal +/-10% |
| Mains fuse | External |
| Fuse type | T10AT |
| Other features | Automatic soft start |
| DSP System | |
| Comms Facilities | Firmware updatable and selected parameters editable |
| Communications | Serial - RS485 Proprietary message format |
| Dynamic Range | 112 dB (A) typical |
| DSP | 3rd generation SHARC |
| Sampling Frequency | 96 kHz 24 bit A/S-D/A word length |
| Format | 1 IN - 2 OUT |
| Construction | |
| Enclosure | 54.9 litres, 18 mm birch plywood, vented and internally braced |
| Finish | Textured black or white paint (custom colours on request) Powder coated perforated steel grille Airnet cloth behind |
| Connectors | 1 x female XLR (input) 1 x male XLR (link) 1 x RJ45 (network in) 1 x RJ45 (network link) 1 x Neutrik Powercon |
| Controls & Indicators | LED on front of cabinet behind grille (wink indicator for locating & assigning) Power LED (blue) Signal LED (green) Limit LED (red) User DSP - defeat switch Power switch |
| Dimensions (H x W x D) | 590 x 450 x 420 mm |
| Weight | 29 kg |
