Ausstattungsliste: VAC Master
Ausstattung & technische Daten
| Technical specification | |
| Gain | 12 dB |
| Inputs | 3 sets RCA line input |
| 2 sets balanced/RCA selectable inputs | |
| 1 set balanced/RCA cinema bypass input | |
| Optional 1 MM and 1 MC (or additional line input if phono is not fitted) | |
| Outputs | 2 sets RCA |
| 2 sets balanced XLR (EIA “pin 2 hot” studio standard) | |
| Tubes | 2x 8416, 7308, 6922, E88CC, ECC88, 6DJ8, (or 12DJ8 twin triodes) |
| Absolute Phase | correct from all inputs to all outputs |
| Frequency Response | Flat over audio band –3 dB bandwidth 5 Hz – 210 kHz |
| THD | <0.009% @ 1 kHz, 1 V RMS |
| Maximum Output | < 8 V RMS |
| Output Impedance | > 150 ohms, 20 Hz - 20 kHz, static (i.e., not dependent upon feedback) |
| Maximum Input | Infinite signal (attenuation precedes the gain circuitry) |
| Recommended Output Load | > 300 ohms |
| Power | External power supply, detachable umbilical cable, detachable IEC power cord Unity gain from selector, non-inverting for archival integrity |
| Cinema Bypass | Yes |
| Voltage | May be factory configured for operation at 100, 120, 220, or 230/240 volts |
| Remote Control | included |
| Illumination | Illuminated logo may be switched off |
| Finish | Hand-rubbed gold-flake gloss black lacquer with chrome knobs standard. |
| Hand-rubbed metallic gloss silver lacquer with chrome knobs special order with additional cost. | |
| Dimensions (H x W x D) | Audio chassis (not including knobs and connectors): 5.5" x 18" x 14.5" (14 cm x 45.7 cm x 36.8 cm) |
| Power supply (not including connectors): 4.3" x 18" x 14.5" (10.9 cm x 45.7 cm x 36.8 cm) | |
| Shipping Weight | With phono: 75 lbs. (27.7 kg.) |
| Optional Phono Stage Technical Specifications | |
| Tubes | 6x 12AX7 |
| Gain | 44 dB MM |
| 64 dB MC | |
| Frequency Response | RIAA standard +/- 0.2 dB (20 Hz - 20 kHz) -3 dB bandwidth 10 Hz - • 80 kHz |
| Channel Separation | > 80 dB @ 1 kHz |
| Maximum Input | > 130 mv @ 1 kHz, MM |
| > 13 mv, MC | |
| MC Load Impedance | selectable, 470, 300, 250, 200, 150, and 100 ohms |
| MM Load Impedance | selectable, 47k, 30k, 25k, 15k, and 10k ohms |
| Overload | 117MV @ 1kHz = 8 volts RMS output; 460MV @ 10kHz |
| Residual Noise | Less than 3MV at output (s/n ratio greater than approx. 69db) |
