Ausstattungsliste: Grace Design FELiX
Ausstattung & technische Daten
| Technical Specifications | |
| Studio Quality 2 Channel Instrument & Mic Preamplifier / DI / EQ | |
| GAIN RANGE (Input to DI Output) | |
| CH1 Mic input | 21-62dB |
| CH1 Instument input | Low Gain: 3-44dB |
| High Gain: 21-62dB | |
| CH2 Instument input | -1.5-36.5dB |
| Boost | 0-9dB |
| THD+N 1kHz, 22Hz-22kHz BW (MIC Input to DI Output) | |
| @ 20dB Gain +10dBu out | <0.0045% |
| @ 40dB Gain +10dBu out | <0.0050% |
| @ 60dB Gain +10dBu out | <0.010% |
| INTERMODULATION DISTORTION - SMPTE/DIN 4:1 7kHz/50Hz (MIC Input to DI Output) | |
| @ 40dB Gain +10dBu out | <0.05% |
| NOISE - REFERRED TO INPUT CH1 MIC @60dB Gain 22Hz-22kHz BW | |
| 50Ω source | <-128dB |
| CMRR @60dB Gain | |
| 100Hz | >55dB |
| 1kHz | >75dB |
| 10kHz | >75dB |
| FREQUENCY RESPONSE (Input to DI Output) | |
| Mic input @ 40dB Gain -3dB | 20Hz – 65kHz |
| Inst input @ 20dB Gain -3dB | 20Hz – 65kHz |
| I/O IMPEDANCE | |
| CH1 MIC Input | 8.1kΩ |
| CH1 Inst Input | HI: 10MegΩ |
| MED: 1MegΩ | |
| LOW: 10kΩ | |
| CH2 Inst Input | HI: 20MegΩ |
| MED: 1MegΩ | |
| LOW: 332kΩ | |
| Insert Input | 10kΩ |
| DI Outputs | 150Ω |
| Amp, Tuner, Headphone and Insert Outputs | 150Ω |
| SIGNAL / PEAK LED METER | |
| Green threshold | -10dBu |
| Red threshold | +10dBu |
| MAXIMUM INPUT LEVEL | |
| CH1 MIC | 0dBu |
| CH1 Inst | Low Gain: +21dBu |
| High Gain: 0dBu | |
| CH2 Inst | +20.5dBu |
| MAXIMUM OUTPUT LEVEL - 100k Ohm load, 0.1% THD | |
| DI Outputs | Line: +20dBu |
| Mic: -6dBu | |
| Amp, Tuner, Headphone and Insert Outputs | +22dBu |
| High Pass Filter / Notch Filter | |
| High Pass Filter | 20Hz – 1kHz @ -12dB/octave |
| Notch Filter | 20Hz – 1kHz, >-35dB, Q>1.0 |
| EQ | |
| Gain | +/- 12dB |
| Low Frequency | Low Range: 125Hz Shelving |
| High Range: 250Hz Shelving | |
| Mid Frequency | Low Range: 70Hz – 880Hz |
| High Range: 670Hz – 8kHz | |
| Mid Frequency Q | 0.5 – 5 |
| High Frequency | 2kHz Shelving |
| OUTPUT NOISE 22Hz-22kHz BW @ MIN Gain | |
| CH1 MIC Input (50 ohms) to DI Output | <-88dBu |
| CH1 Inst Input to DI Output | <-88dBu |
| CH2 Inst Input to DI Output | <-98dBu |
| EXTERNAL FOOTSWITCH | |
| MUTE (TIP) | Momentary – Normally Open – Switch to GND < 10Ω |
| BOOST / TOGGLE (RING) | Momentary – Normally Open – Switch to GND < 10Ω |
| POWER CONSUMPTION | |
| 100-240VAC 50/60Hz | 10 Watts Max |
| WEIGHT and DIMENSIONS | |
| Weight | 3.2lbs |
| Dimensions | H3.0” x W9.5” x D5.5” |
