Ausstattungsliste: Audio Research GS150
Ausstattung & technische Daten
| Tecnical Details | |
| POWER OUTPUT | 155 watts per channel continuous from20Hz to 20kHz. 1kHz total harmonic distortion typically 0.6% at 155 watts, below 0.03% at 1 watt.Approximate actual power available at ‘clipping’ 160 watts (1kHz). |
| (Note that actual power output is dependent upon both line voltage and ‘condition’ i. e.: if power line has high distortion, maximum power will be affected adversely, although from a listening standpoint this is not very critical.) | |
| POWER BANDWIDTH | (-3dB points) 5Hz to 80kHz. |
| FREQUENCY RESPONSE | (-3dB points at 1 watt) 0.5Hz to 120 kHz. |
| INPUT SENSITIVITY | 2.0V RMS BAL for rated output. (24 dB Bal gain into 8 ohms.) |
| INPUT IMPEDANCE | 300K ohms Balanced. |
| OUTPUT POLARITY | Non-inverting. Balanced input pin 2+ (IEC-268). |
| OUTPUT TAPS | 8 ohms, 4 ohms. |
| OVERALL NEGATIVE FEEDBACK | 14dB. |
| SLEW RATE | 13 volts/microsecond. |
| RISE TIME | 2.0 microseconds. |
| HUM & NOISE | Less than 0.1mV RMS – 114dB below rated output (IHF weighted, input shorted).Controls: Rotary selector for tube bias, Power on/off, fan speed, auto shut-off on/defeat, RS232, 12V trigger |
| POWER SUPPLY ENERGY STORAGE | Approximately 1040 joules. |
| POWER REQUIREMENTS | 105-125VAC 60Hz (210-250VAC 50Hz) 730 watts at rated output, 900 watts maximum, 420 watts idle. |
| TUBES REQUIRED | 4 – Matched pair KT150 – Power Output; 4 – 6H30 Driver. |
| DIMENSIONS | 19" (48.3 cm) W x 9 3/8" (23.8 cm) H x 22 3/4" (57.8 cm) D. |
| WEIGHT | TBA |
