Ausstattungsliste: Kramer KT-10
Ausstattung & technische Daten
| SPECIFICATION | |
| TYP | 10” Wall and Table Mount PoE Touch Panel |
| PORTS | 1 USB 2.0 host type A, 1 micro USB 2.0, 3 add–on USB 2.0 module slots (for future use), 2 control I/O ports (for future use), 1 LAN on an RJ–45 connector, 1 headphone port on a 3.5mm mini jack, 1 12 VDC input connector |
| SPEAKERS | 2x1.5W |
| MICROPHONE | 1 omni–directional, — 40 ±3dB sensitivity |
| CPU PERFORMANCE | Quad Core, 1.6GHz, GPU, 2GB RAM, 8GB Flash |
| OS SOFTWARE | Android 4.4.4 KitKat |
| EXTERNAL MEMORY OPTION | SD card (SDHC class 10 compatible) slot (with cover) |
| MULTI TOUCH | 5 points |
| DISPLAY | 10.1" IPS LCD, 16:10 aspect ratio, 1280x800 RGB pixels, back–light, 350 nits brightness, 500:1 contrast ratio |
| VIDEO FORMAT | MKV, TS, FLV, AVI, VOB, MPG, DAT, ASF, RM, MOV, 3GP, MP4 and WMV |
| AUDIO FORMAT | MP2, WMA, WAV, AAC, OGG and ASF |
| IMAGE FORMAT | JPG, BMP and GIF |
| ETHERNET PORT | 10/100Mbps POE LAN, LED (green: Link ON and Idle, flashing green: link ON with activity, light off: link OFF) |
| WIRELESS COMMUNICATION | Wi–Fi IEEE802.11b/g/n Bluetooth BT4.0 |
| CAMERA | Front:2M pixels |
| CLOCK BATTERY | Lithium–ion non–chargeable coin battery (for RTC) |
| CONTROLS | Control buttons: volume (+/–) key, up/down key, exit button, power switch (ON/OFF) and LED (green: ON, red: SW boot–up, light off: OFF) |
| POWER INPUTS | Power over Ethernet (complies with IEEE802.3af and IEEE802.3at PoE standards), power supply unit |
| POWER CONSUMPTION | 12V, 2A 12V/2.0A AC/DC adapter, 1.4A |
| OPERATING TEMPERATURE | 0° to +40°C (32° to 104°F) |
| STORAGE TEMPERATURE | –10° to +55°C (14° to 131°F) |
| HUMIDITY | 10% to 90%, RHL non–condensing |
| CASE DESIGN | Black body and cover |
| INCLUDED ACCESSORIES | Power supply unit, tabletop mount unit, on–wall mount bracket, panel–mount bracket, installation screws |
| CERTIFICATIONS | CE, FCC, ROHS |
| MOUNTING OPTIONS | Panel–back 4 VESA–compatible screw holes |
| PRODUCT DIMENSION | 25.21cm x 18.00cm x 3.00cm (9.93" x 7.09" x 1.18" ) W, D, H |
| PRODUCT WEIGHT | 0.6kg (1.4lbs) approx |
