Ausstattungsliste: AMX NX-1200
Ausstattung & technische Daten
| Specification | |
| Type | NetLinx NX Integrated Controller |
| Dimensions (HWD) | 1 11/16” x 5 13/16” x 5 1/8” (42.16 mm x 147.32 mm x 130.81 mm) |
| Weight | 1.6 lb. (.726 Kg) |
| Memory | Memory Card: 4 GB SD, NVRAM: 1 MB, DDRAM: 512 MB, Note: Supports external USB Solid State Drives |
| Power Consumption | Active Power Consumption: 3 W |
| AxLink Port | (1) 4-position 3.5mm Screw Terminal, provides data and power to external AxLink control devices |
| AxLink Indicator | (1) AxLink LED (green) indicates the state of the AxLink port |
| RS-232/422/485 Ports | (1) 10-position 3.5mm Screw Terminal, NetLinx Port 1, XON/XOFF (transmit on / transmit off), CTS/RTS (clear to send/ready to send), 300 - 115,200 baud |
| RS-232 Port | (1) 5-position 3.5mm Screw Terminal, NetLinx Port 2, XON/XOFF (transmit on / transmit off), CTS/RTS (clear to send/ready to send), 300 - 115,200 baud |
| Serial Indicator | (2) sets of LEDs (red/yellow) indicate when serial Ports 1 and 2 are transmitting and receiving |
| IR/Serial | (2) 2-position 3.5mm Screw Terminal, 2 IR Transmit / 1-way Serial ports, NetLinx Ports 11-12, Support high-frequency carriers up to 1.142 MHz, 2 IR/Serial data signals can be generated simultaneously |
| IR/Serial Indicators | (2) LEDs (red) indicate when each of the IR/Serial ports (11-12) are transmitting control data |
| I/O Channels | (4) One 6-position 3.5mm Screw Terminal, 4-channel binary I/O port for contact closure with each input being capable of voltage sensing, NetLinx Port 22, Channels 1-4 |
| I/O Indicator | (4) LEDs (yellow) indicate each of the I/O channels (1-4) are active |
| IR/RX Ports | (1) 1/8” mini-jack |
| IR/RX Indicator | (1) IR RX LED (red) LED lights when IR data is being received via the IR/RX port |
